Series 422

FEATURES

  • Resolution: 0.001mm
  • AGD2 series, dial face dia. Ø2.20" / Ø58mm
  • Easy to read dial face
  • A pair of limit hands are provided for quick and easy tolerance judgment.
  • Provided with an improved resistance to shop-floor contaminants such as water and dust.
  • With Ø8mm stem diameter

PRODUCT SPECIFICATIONS

RangeGraduationDial ReadingAccuracyCode No.
±0.4mm 0.01mm 40-0-40 0.009mm 422-01-0
RangeGraduationDial ReadingAccuracyCode No.
±0.08mm 0.001mm 90-0-90 0.009mm 422-02-1
±0.2mm 0.005mm 20-0-20 0.009mm 422-03-1
±0.08mm 0.002mm 90-0-90 0.009mm 422-04-1
±0.4mm 0.01mm 40-0-40 0.009mm 422-05-1
