| Range | Accuracy | Graduation | Spindle Dia. | Spindle Lock | Measuring Face | Clamp Nut | Code No. | |
|---|---|---|---|---|---|---|---|---|
| 0-.5" | ± .0001" | .001" | Φ0.197" | With | Flat | W/O | 169-06-1 | |
| 0-.5" | ± .0001" | .001" | Φ0.197" | With | Spherical | W/O | 169-06-3 | |
| 0-.5" | ± .0001" | .001" | Φ0.197" | W/O | Spherical | With | 169-06-5 | |
| 0-.5" | ± .0001" | .001" | Φ0.197" | W/O | Flat | W/O | 169-13-1 | |
| 0-.5" | ± .0001" | .001" | Φ0.197" | With | Flat | W/O | 169-13-3 | |
| 0-.5" | ± .0001" | .001" | Φ0.197" | W/O | Spherical | W/O | 169-13-5 | |
| 0-.5" | ± .0001" | .001" | Φ0.197" | With | Spherical | W/O | 169-13-7 | |
| 0-.5" | ± .0001" | .001" | Φ0.197" | W/O | Flat | With | 169-23-1 | |
| 0-.5" | ± .0001" | .001" | Φ0.197" | With | Flat | With | 169-23-3 | |
| 0-.5" | ± .0001" | .001" | Φ0.197" | W/O | Spherical | With | 169-23-5 | |
| 0-.5" | ± .0001" | .001" | Φ0.197" | With | Spherical | With | 169-23-7 | |
| 0-.5" | ± .0001" | .0002" | Φ0.197" | W/O | Flat | W/O | 169-33-1 | |
| 0-.5" | ± .0001" | .0002" | Φ0.197" | W/O | Carbide & Spherical | W/O | 169-33-3 | |
| 0-.5" | ± .0001" | .0002" | Φ0.197" | W/O | Flat | With | 169-33-5 | |
| 0-.5" | ± .0001" | .0002" | Φ0.197" | W/O | Spherical | With | 169-33-7 | |
| 0-.5" | ± .0001" | .001" | Φ0.197" | W/O | Carbide & Flat | W/O | 169-43-1 | |
| 0-.5" | ± .0001" | .001" | Φ0.197" | W/O | Carbide & Spherical | W/O | 169-43-3 | |
| 0-.5" | ± .0001" | .001" | Φ0.197" | W/O | Carbide & Flat | With | 169-43-5 | |
| 0-.5" | ± .0001" | .001" | Φ0.197" | W/O | Carbide & Spherical | With | 169-43-7 |
| Range | Accuracy | Graduation | Spindle Dia. | Spindle Lock | Measuring Face | Clamp Nut | Code No. | |
|---|---|---|---|---|---|---|---|---|
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | With | Flat | W/O | 169-06-0 | |
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | With | Spherical | W/O | 169-06-2 | |
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | W/O | Spherical | With | 169-06-4 | |
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | W/O | Flat | W/O | 169-13-0 | |
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | With | Flat | W/O | 169-13-2 | |
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | W/O | Spherical | W/O | 169-13-4 | |
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | With | Spherical | W/O | 169-13-6 | |
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | W/O | Flat | With | 169-23-0 | |
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | With | Flat | With | 169-23-2 | |
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | W/O | Spherical | With | 169-23-4 | |
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | With | Spherical | With | 169-23-6 | |
| 0-13mm | 0.004mm | 0.005mm | Φ5mm | W/O | Flat | W/O | 169-33-0 | |
| 0-13mm | 0.004mm | 0.005mm | Φ5mm | W/O | Carbide & Spherical | W/O | 169-33-2 | |
| 0-13mm | 0.004mm | 0.005mm | Φ5mm | W/O | Flat | With | 169-33-4 | |
| 0-13mm | 0.004mm | 0.005mm | Φ5mm | W/O | Spherical | With | 169-33-6 | |
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | W/O | Carbide & Flat | W/O | 169-43-0 | |
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | W/O | Carbide & Spherical | W/O | 169-43-2 | |
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | W/O | Carbide & Flat | With | 169-43-4 | |
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | W/O | Carbide & Spherical | With | 169-43-6 |
