| Range | Accuracy | Graduation | Spindle Dia. | Spindle Lock | Measuring Face | Clamp Nut | Code No. | |
|---|---|---|---|---|---|---|---|---|
| 0-1" | ± .0001" | .001" | Φ0.315" | With | Carbide & Flat | W/O | 169-55-1A | |
| 0-1" | ± .0001" | .001" | Φ0.315" | With | Carbide & Spherical | W/O | 169-56-1 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | With | Carbide & Flat | W/O | 169-57-1 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | With | Carbide & Spherical | W/O | 169-58-1 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | With | Carbide & Flat | W/O | 169-55-3 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | With | Carbide & Spherical | W/O | 169-56-3 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | With | Carbide & Flat | W/O | 169-57-3 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | With | Carbide & Spherical | W/O | 169-58-3 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | With | Carbide & Flat | With | 169-55-5 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | With | Carbide & Spherical | With | 169-56-5 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | with | Carbide & Flat | with | 169-57-5 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | With | Carbide & Spherical | With | 169-58-5 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | With | Carbide & Flat | With | 169-55-7 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | With | Carbide & Spherical | With | 169-56-7 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | With | Carbide & Flat | With | 169-57-7 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | With | Carbide & Spherical | With | 169-58-7 | |
| 0-2" | ± .0001" | .001" | Φ0.256" | W/O | Carbide & Flat | W/O | 169-81-1 | |
| 0-2" | ± .0001" | .001" | Φ0.256" | W/O | Carbide & Spherical | W/O | 169-81-3 | |
| 0-2" | ± .0001" | .001" | Φ0.256" | W/O | Carbide & Flat | With | 169-81-5 | |
| 0-2" | ± .0001" | .001" | Φ0.256" | W/O | Carbide & Spherical | With | 169-81-7 | |
| 0-.5" | ± .0001" | .001" | Φ0.157" | W/O | Flat | W/O | 169-91-1 | |
| 0-.5" | ± .0001" | .001" | Φ0.197" | W/O | Spherical | With | 169-91-3 |
| Range | Accuracy | Graduation | Spindle Dia. | Spindle Lock | Measuring Face | Clamp Nut | Code No. | |
|---|---|---|---|---|---|---|---|---|
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | With | Carbide & Flat | W/O | 169-55-0A | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | With | Carbide & Spherical | W/O | 169-56-0 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | With | Carbide & Flat | W/O | 169-57-0 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | With | Carbide & Spherical | W/O | 169-58-0 | |
| 0-25mm | 0.004mm | 0.001mm | Φ8mm | With | Carbide & Flat | W/O | 169-55-2 | |
| 0-25mm | 0.004mm | 0.001mm | Φ8mm | With | Carbide & Spherical | w/o | 169-56-2 | |
| 0-25mm | 0.004mm | 0.001mm | Φ8mm | With | Carbide & Flat | W/O | 169-57-2 | |
| 0-25mm | 0.004mm | 0.001mm | Φ8mm | With | Carbide & Spherical | W/O | 169-58-2 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | With | Carbide & Flat | With | 169-55-4 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | With | Carbide & Spherical | With | 169-56-4 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | With | Carbide & Flat | With | 169-57-4 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | With | Carbide & Spherical | With | 169-58-4 | |
| 0-25mm | 0.004mm | 0.001mm | Φ8mm | With | Carbide & Flat | With | 169-55-6 | |
| 0-25mm | 0.004mm | 0.001mm | Φ8mm | With | Carbide & Spherical | With | 169-56-6 | |
| 0-25mm | 0.004mm | 0.001mm | Φ8mm | With | Carbide & Flat | With | 169-57-6 | |
| 0-25mm | 0.004mm | 0.001mm | Φ8mm | With | Carbide & Spherical | With | 169-58-6 | |
| 0-50mm | 0.004mm | 0.01mm | Φ6.5mm | W/O | Carbide & Flat | W/O | 169-81-0 | |
| 0-50mm | 0.004mm | 0.01mm | Φ6.5mm | W/O | Carbide & Spherical | W/O | 169-81-2 | |
| 0-50mm | 0.004mm | 0.01mm | Φ6.5mm | W/O | Carbide & Flat | With | 169-81-4 | |
| 0-50mm | 0.004mm | 0.01mm | Φ6.5mm | W/O | Carbide & Spherical | With | 169-81-6 | |
| 0-13mm | 0.004mm | 0.01mm | Φ4mm | W/O | Flat | W/O | 169-91-0 | |
| 0-13mm | 0.004mm | 0.01mm | Φ5mm | W/O | Spherical | With | 169-91-2 |
