Snap Gauges

Series 181
Snap Gauges
  • Snap Gauges

FEATURES

  • Carbide tipped measuring faces
  • Dial gauge is not included and it is optional, refer to 422-21-1 or 422-21-2
    (The measuring resolution is indicative of the dial gauge)
  • 8mm diameter stem dial gauge
  • Suitable for quickly measuring dimensions of mass-produced work pieces
  • Type A and type B measuring anvil configurations are available
Inquiry

PRODUCT SPECIFICATIONS

INCH METRIC
RangeAnvil TypeCode No.
0-1" A 181-01-1
0-2" A 181-02-1
2-4" A 181-04-1
4-6" A 181-06-1
6-8" A 181-08-1
0-1.5" B 181-01-3
1.5-3.5" B 181-02-3
3.5-5.5" B 181-04-3
5.5-7.5" B 181-06-3
RangeAnvil TypeCode No.
0-25mm A 181-01-0
0-50mm A 181-02-0
50-100mm A 181-04-0
100-150mm A 181-06-0
150-200mm A 181-08-0
0-40mm B 181-01-2
40-90mm B 181-02-2
90-140mm B 181-04-2
140-190mm B 181-06-2
