Digital Tube Micrometers

Series 147
Digital Tube Micrometers
  • Digital Tube Micrometers

FEATURES

  • Resolution: .00005" / 0.001mm
  • Protection level IP65
  • For measuring wall thickness of various tubes
  • Anvils J and Anvils K are optional
  • Carbide tipped measuring faces
  • Inch/Metric conversion
  • Read the actual absolute measuring position upon switching on the display
  • Automatic On/Off to maximize battery life
  • Absolute or incremental measuring modes
  • Support Bluetooth data transmission
    Bluetooth data output: 901-01-5
Inquiry

PRODUCT SPECIFICATIONS

INCH METRIC
RangeAccuracyAnvil Type Code No.
0-1"/0-25mm ± .0001" J 147-01-1
1-2"/25-50mm ± .0002" J 147-02-1
2-3"/50-75mm ± .0002" J 147-03-1
3-4"/75-100mm ± .0002" J 147-04-1
0-1"/0-25mm ± .0001" K 147-01-3
1-2"/25-50mm ± .0002" K 147-02-3
2-3"/50-75mm ± .0002" K 147-03-3
3-4"/75-100mm ± .0002" K 147-04-3
RangeAccuracyAnvil TypeCode No.
0-25mm/0-1" ± 0.002mm J 147-01-0
25-50mm/1-2" ± 0.002mm J 147-02-0
50-75mm/2-3" ± 0.003mm J 147-03-0
75-100mm/3-4" ± 0.003mm J 147-04-0
0-25mm/0-1" ± 0.002mm K 147-01-2
25-50mm/1-2" ± 0.002mm K 147-02-2
50-75mm/2-3" ± 0.003mm K 147-03-2
75-100mm/3-4" ± 0.003mm K 147-04-2
